锟斤拷锟絘(ch锟斤拷n)锟斤拷 / Manufacturer: | 锟铰拷锟斤拷锟斤拷锟紽(tu锟斤拷n)锟斤拷锟斤拷锟絶锟截ｏ拷Gildemeister锟斤拷 |
锟斤拷 號(h锟斤拷o) / Machine Model: | MF Twin 65 |
锟斤拷 锟斤拷 / Year of Manufacturer: | 1999 |
锟斤拷锟斤拷號(h锟斤拷o) / Serial Number: | 锟斤拷1锟絖(t锟斤拷i)锟斤拷 4280001161 |
| 锟斤拷2锟絖(t锟斤拷i)锟斤拷 4280001171 |
系 锟統(t锟斤拷ng) / Control system: | Siemens 840C |
锟斤拷锟紻(zhu锟斤拷n)直锟斤拷 / Swing diameter: | 240 mm |
車锟斤拷直锟斤拷 / Turning diameter: | 200 mm |
锟斤拷锟絊锟斤拷锟絰 / Spindle distance: | 800 mm |
锟斤拷锟�1锟叫筹拷 / Slide 1 flat & length travel: | 199/555 mm |
锟斤拷锟�2锟叫筹拷 / Slide 2 flat & length travel: | 199/555 mm |
锟斤拷锟絊2锟叫筹拷 / Spindle 2 length travel: | 600 mm |
锟斤拷锟斤拷锟絊1-锟斤拷锟�(c锟斤拷) / Spindle 1- Left: |
|
Chuck diameter: | 200 mm |
Max. bar diameter: | 65 mm |
Spindle bore: | 79 mm |
Clamping tube inner diameter: | 66 mm |
Front bearing diameter: | 120 mm |
锟斤拷锟斤拷锟絊2-锟揭傦拷(c锟斤拷) / Spindle 2 - Right: |
|
Chuck diameter: | 200 mm |
Max. bar diameter: | 42 mm |
Spindle bore: | 56 mm |
Clamping tube inner diameter: | 44 mm |
Front bearing diameter: | 90 mm |
锟斤拷锟斤拷锟�(q锟斤拷)锟斤拷(d锟斤拷ng)锟斤拷1-锟斤拷锟�(c锟斤拷) / Main Drive 1- Left: |
|
Max. drive power (40/100% ED): | 28/21 kW |
Range of speed: | 25~5000 rpm |
Max. drive torque (40/100% ED): | 320/240 Nm |
C axis speed: | 250 rpm |
C axis torque: | 200 Nm |
Accuracy: | 0.025 锟斤拷 |
锟斤拷锟斤拷锟�(q锟斤拷)锟斤拷(d锟斤拷ng)锟斤拷2-锟揭傦拷(c锟斤拷) / Main Drive 2 - Right: |
|
Max. drive power (40/100% ED): | 18/14 kW |
Range of speed: | 31~6300 rpm |
Max. drive torque (40/100% ED): | 130/173 Nm |
C axis speed: | 250 rpm |
C axis torque: | 120 Nm |
Accuracy: | 0.025 锟斤拷 |
锟斤拷锟斤拷锟�1-锟较诧拷 / Slide 1 - Upper: |
|
X/Z feed rate: | 20/30 m/min |
Feed force: | 400/700 daN |
Travel resolution: | 0.001 mm |
Spindle pitch: | 12x28/15x32 mm |
锟斤拷锟斤拷锟�2-锟铰诧拷 / Slide 2 - Lower: |
|
X/Z feed rate: | 20/30 m/min |
Feed force: | 400/700 daN |
Travel resolution: | 0.001 mm |
Spindle pitch: | 12x28/15x32 mm |
锟斤拷锟斤拷锟斤拷1锟斤拷2 / Tool Carrier 1 & 2: |
|
Capacity: | 2 x 12 |
Shaft diameter (DIN 69880): | 30 mm |
Max. drive power (40/100% ED): | 7/5 kW |
Max. drive torque (40/100% ED): | 22/15 Nm |
Range of speed: | 40~4200 rpm |
锟斤拷锟轿尺寸（锟絃(zh锟斤拷ng)x锟斤拷x锟竭ｏ拷 / Dimensions (L x W x H): | 4770 x 2220 x 1950 mm |
锟紺(j锟斤拷)锟斤拷毛锟斤拷 / Gross weight: | 6500 kg |
锟斤拷锟斤拷邊锟絙锟矫和革拷锟斤拷 / Equipments and Accessories: | 锟斤拷锟斤拷锟斤拷锟斤拷锟紺(j锟斤拷)锟较碉拷電氾拷锟� / Integrated electric cabinet. |
锟斤拷锟絇锟斤拷锟斤拷 / Jaws for chucks. |
锟斤拷屑锟斤拷 / Chip conveyors. |
锟斤拷锟斤拷锟斤拷 / Bar feeders. |
锟斤拷锟斤拷 / Tool holders. |
锟斤拷(d锟斤拷ng)锟斤拷锟斤拷锟斤拷锟斤拷锟斤拷锟斤拷 / Power tool seats and others. |
锟斤拷锟絞(sh锟斤拷)锟結锟斤拷 / Technical documents. |
